Wall-Box-Mounted-Car-Floor-Standing-Ev Charger-Company-RENOPI

Easily Full of Electricity at Home

Efficient and fast chargingIntelligent adjustmentIP65 protectionAPP Remote MonitoringEasy Installation

Easy
Installation
RFID
Card
High
Security
APP Remote
Monitoring

Charge Smarter, Drive Further

Efficient and fast charging, single-phase maximum power 7.4KW, 3-phase maximum power 22KW, easily full of electricity at home.
Intelligent adjustment of charging speed according to energy supply, ensuring charging efficiency and safety.
Support APP control, real-time charging status and charging reservation.
IP65 protection, easily cope with bad weather.
Adopt the OCPP protocol to meet all mainstream EV brand in the market.

Technical Parameters

RENOPI MODEL	RENOPI EV Charger 7.4	RENOPI EV Charger 22
Inputs and outputs(AC)
Max. Charge Power	7.4KW	22KW
Power Supply	1P+N+PE	3P+N+PE
Nominal Voltage	230V	400V
Nominal Frequency	50/60Hz	50/60Hz
Nominal Current	Max.32A; Single-phase	Max.32A; Three-phase
General
Connector	Type 2 Cable
Cable Length	5m (3.5m or 7m Optional)
Communication	Wi-Fi/Bluetooth(Optional)
Start Mode	APP/Plug&Charge/RFID
Communication Protocol	OCPP 1.6
Installation	Floor/Wall-mounting
Protection Degree	IP65
Environment Temperature	-25°C ~ +50°C
Relative Humidity	5-95% non-condensing
Cooling	Natural cooling
Standby Power Consumption	<6W
Dimension (W/H/D)	432232100mm	432232100mm
Weight	4.9KG	5.1KG
Accessories	RFID Card * 2
Certification Standard	CE, TUV, IEC 61851-21, IEC 61851-1
